XC tech Cinema Gong: pre-show gong in 5.1 and 7.1

A surround pre-show gong for 5.1 and 7.1 auditoriums. Three versions (Modern, Cinematic and Klasik) as SMPTE DCPs at reference level.

New · 13/10/2026

Three versions

Gong Modern

8.5 s

A modern sound logo. Three soft metallic notes start behind the audience, travel along the sides of the auditorium and land on the screen in a warm chord with a deep bass.

Download 5.1· 86 MB Download 7.1· 86 MB

Gong Cinematic

8.5 s

The same motif dressed for the movies: a timpani crescendo, French horns and a soft choir.

Download 5.1· 86 MB Download 7.1· 86 MB

Gong Klasik

12 s

The traditional three-tone gong, high, middle and deep, in a clean surround version.

Download 5.1· 121 MB Download 7.1· 121 MB

YouTube plays 5.1 at most, the full eight channels of 7.1 are only in the downloadable DCP.

Files and SHA-256

XCT-GongModern_XSN-1_F_XX-XX_INT-TD_51_2K_NULL_20261013_NUL_SMPTE_OV.zip · 86 MBSHA-256 4ca5e70e1b9974537fe42d8f905d9c4223b85801e0b348d8609201eb264a701f
XCT-GongModern_XSN-1_F_XX-XX_INT-TD_71_2K_NULL_20261013_NUL_SMPTE_OV.zip · 86 MBSHA-256 ff5dcd36e555be602730aceaf357a0d9379689a80a7b4658991b71692ad1561f
XCT-GongCinematic_XSN-1_F_XX-XX_INT-TD_51_2K_NULL_20261013_NUL_SMPTE_OV.zip · 86 MBSHA-256 f8a227fd79f9f513fc7e63fbb521bd7e933ba6a657dbdf71219415abf1ce55bb
XCT-GongCinematic_XSN-1_F_XX-XX_INT-TD_71_2K_NULL_20261013_NUL_SMPTE_OV.zip · 86 MBSHA-256 cd2951c328d96924f8fb5b947e7471ff323cb01643f291d8c6ae875a5f0d28a8
XCT-GongKlasik_XSN-1_F_XX-XX_INT-TD_51_2K_NULL_20261013_NUL_SMPTE_OV.zip · 121 MBSHA-256 19cee062c03c04a4cb93ca8bcbd29e09293fbb15a9f2b4f08fdd9f7e52575b24
XCT-GongKlasik_XSN-1_F_XX-XX_INT-TD_71_2K_NULL_20261013_NUL_SMPTE_OV.zip · 121 MBSHA-256 7a19acfc390dc2cbaddfbff6c46adb826aaf149002ee7f23ea855fda222dee04

Surround mix

The gongs are mixed for the auditorium in both 5.1 and 7.1: the sound moves through the room, the surrounds ring out and the subwoofer gives the finale its weight.

Reference level

All gongs are set to cinema reference: at fader 7 they play like a well mixed feature (the loudest second in the centre channel is 85 dBC).

Technical details

Format: SMPTE DCP (Bv2.1), unencrypted, no KDM
Picture: 2K Flat 1998 × 1080, 24 fps, black picture, content type XSN
Sound: 24 bit / 48 kHz, 16-channel PCM with SMPTE MCA labels
5.1: 1 L, 2 R, 3 C, 4 LFE, 5 Ls, 6 Rs
7.1 DS: 1 L, 2 R, 3 C, 4 LFE, 5 Lss, 6 Rss, 11 Lrs, 12 Rrs (set the processor to 7.1 DS)
Level: reference level, fader 7
Verified: DCP-o-matic verify with no findings, channel layout checked
Packaging: uncompressed ZIP, unzip and ingest the folder as it is

Terms of use

You can use the gongs freely in your cinema and pass them on unchanged. They are not for sale.

We will gladly make a gong with your cinema’s logo. Get in touch.

FAQ

What volume should the gong play at?

Reference level, fader 7. The gong then plays like a well mixed feature, with the loudest second in the centre channel at 85 dBC.

Which version should I download, 5.1 or 7.1?

The one that matches the auditorium sound: 7.1 for a room with rear channels (7.1 DS), otherwise 5.1. For 7.1, set the processor to 7.1 DS.

Do I need a KDM for the gongs?

No. The DCPs are unencrypted: unzip the package and ingest the folder into the cinema server, then put the gong in the playlist before the feature.

Can I share or edit the gong?

You can use the gongs freely in your cinema and pass them on unchanged. They are not for sale. We will gladly make a gong with your cinema’s logo.

Test DCPs to set up the auditorium

Before the gong goes into the programme, check the auditorium with our test DCPs: picture, framing, audio channels, sync and surround sound.

DCI alignment pattern→Geometry, convergence, sharpness and colour channels in one chart, with Flat, Scope, F-200 and F-220 framing lines. Full container, 20 s @ 24 fps.Framing F-190 / F-210→F-190 and F-210 framing lines with masking arrows and pixel offsets, plus Flat, Scope and 16:9 for reference. Full container, 20 s @ 24 fps.Audio channel test - 7.1→The 7.1 channels play one after another: first the channel name is spoken, then six seconds of pink noise. Checks the wiring of all eight channels, rear ones included. Flat container, 1:12.Audio/video sync test→Shows whether the sound in the auditorium runs ahead of or behind the picture, and by how many milliseconds. Countdown, offset finder from -100 to +100 ms, clapperboard scene and an L, C, R and LFE channel check. Flat container, 1:03.Surround Worlds: 5.1 and 7.1 music test→Ten music worlds mixed across every channel of 5.1 or 7.1. A 3D auditorium shows which speakers play and where the sound moves, and every track opens with the sound going round the room speaker by speaker. Flat container, 8:20.
