Surround Worlds: 5.1 and 7.1 music test

Ten music worlds mixed across every channel of 5.1 or 7.1. A 3D auditorium shows which speakers play and where the sound moves, and every track opens with the sound going round the room speaker by speaker. Flat container, 8:20.

worlds-v1.0New · 12/10/2026

Download 7.13,88 GB Download 5.13,85 GB

Files and SHA-256

7.1 · SurroundWorlds_TST-1_F_EN-XX_INT-TD_71_2K_NULL_20261012_NUL_SMPTE_OV.zip · 3,88 GBSHA-256 63c1ee36025f1845115b6242495797dff758971bd8cdb3d0aea88bec28b0412b
5.1 · SurroundWorlds_TST-1_F_EN-XX_INT-TD_51_2K_NULL_20261012_NUL_SMPTE_OV.zip · 3,85 GBSHA-256 3dcbfe7dc917a57596af0ae1461d6245f0a0ca95593056938a1287074771e712

What the package contains

Ten music worlds: 8:20 of music in total. Every world is mixed across all channels, and a 3D auditorium on screen shows which speakers are playing and where the sound is moving.
Round the room: Every track opens with the sound going round the auditorium speaker by speaker: L, C, R, Rs, Bsr, Bsl, Ls (L, C, R, Rs, Ls in the 5.1 version).
7.1 DS version: DCP channels: L 1, R 2, C 3, LFE 4, Lss 5, Rss 6, Lrs 11, Rrs 12, the other tracks are silent. SMPTE MCA labels.
5.1 version: DCP channels: L 1, R 2, C 3, LFE 4, Ls 5, Rs 6, the other tracks are silent. SMPTE MCA labels.

How to use the test

1
Download the version that matches the auditorium sound: 7.1 for a room with rear channels (7.1 DS), otherwise 5.1.
2
Unzip the package and ingest the folder into the cinema server as it is.
3
For the 7.1 version, set the processor to 7.1 DS.
4
The mix sits around -24 dBFS RMS. Start around fader 5 to 5.5, then turn it up step by step.
5
During the walk round the room at the start of every track, check that the sound comes from the speaker the auditorium model highlights. Then listen to how the sound moves through the room.

Technical parameters

Container: Flat 1.85:1 · 1998 × 1080
Duration: 8:20 at 24 fps
Audio 7.1: 16-channel PCM 24 bit / 48 kHz, 7.1 DS layout (ISDCF Doc4), SMPTE MCA labels
Audio 5.1: 16-channel PCM 24 bit / 48 kHz, 5.1 on positions 1 to 6, SMPTE MCA labels
Level: music mix around -24 dBFS RMS
Profile: SMPTE Bv2.1
Standard: SMPTE DCP, unencrypted (no KDM), content kind TST
Picture: JPEG 2000 in MXF, X'Y'Z' 12 bit, gamma 2.6 (SMPTE ST 428-1)
Package: ASSETMAP, CPL, PKL, VOLINDEX and MXF in a folder ending in _SMPTE_OV, zipped

Versions

v1.0 (2026-10-12)
- First release: ten music worlds in 5.1 and 7.1 DS versions, 2K Flat, 8:20.

Free for projector alignment, commercial use included, under the licence CC BY-ND 4.0

Frequently asked questions

How is it different from the 7.1 audio channel test?

The 7.1 channel test checks the wiring: one channel at a time, first its name, then pink noise. Surround Worlds is music mixed across all channels at once, so you hear how the auditorium plays as a whole and how the sound moves between speakers.

Why does the YouTube video not play 7.1?

YouTube plays 5.1 at most. The full eight channels of 7.1 are only in the downloadable DCP. The YouTube video is a preview.

What volume should I play it at?

The mix sits around -24 dBFS RMS. Start around processor fader 5 to 5.5, then turn it up step by step.
